Piconode Data Logger
Ultra-compact wireless data logger designed for high-density monitoring in tight spaces. Featuring 3 channels — configurable analog, thermistor, and pulse counter — with up to 25 years of battery life and fully potted IP68 protection for the harshest environments.
Piconode Data Logger
Model: LS-G6-PICO
Analog • Thermistor • Pulse • LoRaWANCompact Wireless Data Acquisition for Tight Spaces
The Piconode is an ultra-compact, 3-channel wireless data logger designed for long-term, unattended monitoring in confined spaces. It includes one configurable analog channel (voltage, potentiometer, Full Wheatstone bridge), one precision thermistor channel, and one pulse counter channel — all in a fully potted, IP68-rated enclosure.
With its compact form factor and long-range LoRa communications, the Piconode is ideal for high-density monitoring applications where space is at a premium — such as manholes, inside structural joints, boreholes, and cramped construction sites.
Voltage, potentiometer & Full Wheatstone bridge
0 Ω to 2 MΩ, accuracy ±0.04°C
0 to 4.3 billion pulses, 0–50 Hz
Encapsulated electronics for extreme conditions
Sensor Compatibility
Versatile analog & pulse interface
The Piconode supports a wide range of analog sensors through its configurable channel, precision thermistor input, and pulse counter — ideal for environmental, geotechnical, and structural monitoring in space-constrained deployments.
Not sure about compatibility?
Contact UsWhat Makes the Piconode Different
Purpose-built for high-density, space-constrained monitoring with versatile sensor inputs and extreme reliability.
Ultra-Compact Design
Fully potted, ultra-compact enclosure designed for installation in manholes, boreholes, structural joints, and other confined spaces where traditional loggers won't fit.
Ultra-Long Battery Life
Up to 25 years of unattended operation with 2-cell configuration. User-replaceable battery with configurable reporting periods from 30 seconds to 24 hours.
Triple-Mode Sensing
3 dedicated channels: configurable analog (voltage/potentiometer/FWB), precision thermistor (0 Ω–2 MΩ), and pulse counter (0–4.3B pulses) — all in one compact device.
IP68 Fully Potted
Industrial-grade fully potted IP68 enclosure. Operating range from −40°C to +80°C — survives submersion and the harshest field conditions.
Long-Range Wireless
LoRaWAN communications reaching up to 4 km in urban environments. Reliable data transmission even from manholes, tunnels, and below-grade installations.
Mobile App Configuration
Wireless Bluetooth setup via Worldsensing App. Wiring assistant, field sampling, signal coverage testing and diagnostics — no laptop needed.
Monitoring Solutions for Every Environment
Explore the wide range of monitoring solutions the Piconode enables across geotechnical, structural, environmental and remote process monitoring.
Geotechnical Monitoring
Pore Water Pressure & Level
Connect piezometers and water level sensors to the configurable analog channel for continuous groundwater monitoring in dams, slopes and excavations.
Cross-Crack Movements
Wireline extensometers, crackmeters and displacement sensors for monitoring tension cracks across landslides and slopes using the analog or pulse input.
Load in Rock Bolts & Ground Anchors
Load cells connected via Full Wheatstone bridge for monitoring anchor systems throughout their lifecycle — from load tests to long-term service.
In-ground Displacement
Multi-point borehole extensometers and displacement sensors for monitoring ground movement in boreholes and excavations.
Structural & Environmental Monitoring
Movements Across Surface Cracks
Crackmeters and draw wire sensors connected to the configurable channel for monitoring surface crack movement in structures.
Temperature Monitoring
Precision thermistor channel for monitoring temperature in concrete, soil and structures. Internal temperature sensor logs with each reading.
Rainfall & Precipitation
Connect tipping bucket rain gauges to the pulse counter channel for remote rainfall monitoring in environmental and hydrological applications.
Open Channel Flow & Pond Level
Level sensors and flow meters connected to the configurable analog or pulse counter channels for monitoring water flow and pond levels.
Remote Process Monitoring
Pressure & Strain Monitoring
Strain gauges and pressure sensors connected via Full Wheatstone bridge for monitoring structural stress and pressure in industrial installations.
Pulse Counting & Flow Totalization
Water meters, flow totalizers, and pulse-output sensors connected to the dedicated pulse counter channel for remote consumption monitoring.
Soil Water Tension & Moisture
Tensiometers and soil moisture sensors for assessing water tension in geotechnical, agricultural and environmental applications.
Dewatering Operations
Monitor water flow and pump activity with flow meters connected to the pulse counter channel for remote dewatering management.
Piconode Data Logger Specifications
| Device Type | Ultra-compact analog wireless data logger |
|---|---|
| Data Transmission | LoRa radio communications (868 MHz or 915 MHz) |
| Channels | 3 channels: 1 configurable, 1 thermistor, 1 pulse counter |
| Configurable Input Types | Voltage (±7.5 mV/V), Potentiometer (0–5 VDC), Full Wheatstone Bridge |
| Thermistor Range | 0 Ω to 2 MΩ |
| Pulse Counter Range | 0 to 4,294,967,295 pulses (0–50 Hz) |
| Sensor Power Output | 5 V DC up to 50 mA |
| Operating Temperature | −40°C to +80°C |
| Weather Protection | IP68 (fully potted) |
| System Configuration | Worldsensing App (Bluetooth) • CMT Edge • CMT Cloud |
| Detailed Sensor Specifications | |||||||||||||||||||||||||||||||||||||||||||||||||
|
Inputs: 3-ch (analog/thermistor/pulse)
Temp: −40°C to +80°C
Protection: IP68 potted
|
Battery @1hr:
1 cell: 8.6 yrs
2 cells: 17.2 yrs
|
|||||||||||||||||||||||||||||||||||||||||||||||||
Need the full technical details?
Complete specs, diagrams, and compatibility info
Flexible Mounting for Any Environment
Choose the mounting configuration that best fits your deployment site.
Pole Mounting
Using aluminum plate WS-ACC-POLE-PL8 with 35 mm or 50 mm u-bolts for secure attachment to poles and posts.
Wall Mounting
Using external mounting brackets LS-ACC-MEC-MP (set of 2) for secure wall installation in tunnels and structures.
Horizontal & Surface Mounting
Using versatile plate LS-ACC-IN15-HP for horizontal and vertical surface deployment in tight spaces.
Got Questions About the Piconode?
Can't find what you're looking for? Contact our team — we're happy to help.
The Piconode is an ultra-compact wireless data logger designed for long-term, unattended monitoring in confined spaces. It captures data from voltage, potentiometer, Wheatstone bridge, thermistor, and pulse-output sensors — making it ideal for environmental, geotechnical, and structural monitoring where space is at a premium.
The Piconode supports voltage (±7.5 mV/V for FWB, 0–5 VDC for single-ended), potentiometer (0–5 VDC), Full Wheatstone bridge, thermistor (0 Ω to 2 MΩ), and pulse counter (0 to 4.3 billion pulses) inputs. This covers load cells, strain gauges, pressure sensors, NTC thermistors, rain gauges, flow meters, displacement sensors, and more.
Battery life depends on the selected reporting period and battery configuration. With a 1-hour reporting interval, the 1-cell configuration achieves 8.6 years, while the 2-cell configuration reaches 17.2 years. With a 6-hour interval, the 2-cell configuration exceeds 25 years. Batteries are user-replaceable.
Absolutely. The Piconode features a fully potted IP68-rated enclosure designed to withstand submersion, dust, and extreme temperatures from −40°C to +80°C. Its ultra-compact, robust design makes it ideal for installation in manholes, boreholes, structural joints, and other harsh environments where traditional loggers would fail.
In open sight, the range can reach up to 15 km (9.3 mi). In dense urban environments, up to 4 km (2.5 mi). When placed in a manhole, the range extends up to 2 km (1.2 mi), and in tunnels it reaches up to 4 km (2.5 mi). Range depends on terrain, environment and antenna configuration.
The Piconode can be configured wirelessly via the Worldsensing App using Bluetooth — no laptop needed. The app provides a wiring assistant, field sampling mode, signal coverage testing, and full diagnostics. For remote management, configuration can be done through CMT Edge or CMT Cloud platforms.
